HDPE Geomembrane & Lining Services
Eight scopes of work covering roll goods, fabrication, welded installation, seam testing and the protection layers that keep a lined structure intact — anywhere in the United Arab Emirates.
Supply, fabrication and installation under one scope
Some clients want rolls delivered to a gate and nothing else. Others want a lined, tested, documented reservoir handed over. We are set up for both ends of that range and everything between, which means you are not forced to buy a service you do not need.
Every service below is priced separately, so a quotation shows you exactly what you are paying for: material, fabrication, deployment, welding, testing and documentation as distinct lines. If you later decide to take the sheet only and weld it yourself, the material line does not change.
What does not change either is the material standard. Whether it is 400 m² of pond liner or 40,000 m² of landfill base, the sheet is supplied against the same published specification with certificates traceable to the delivered rolls.
Describe the structure — a reservoir, a bund, a canal, a fish pond — and the area. We will tell you which of the services below actually apply, and which you can skip.
Geomembrane and lining services
HDPE geomembrane supply
Roll goods in 0.50–3.00 mm, smooth or textured, black or with a white reflective face. Mill certificates issued per consignment against GRI-GM13 and the relevant ASTM test methods.
Geomembrane supplyHDPE liner suppliers in Dubai
Delivery and installation across Dubai — industrial zones, farm reservoirs, district cooling ponds and construction water storage, with short lead times on standard grades.
Liner supply in DubaiHDPE liner sheet
Sheet widths, roll lengths, weights and how to convert a pond drawing into a roll schedule without over-ordering or running short on the last panel.
HDPE liner sheetHDPE liner installation
Subgrade acceptance, panel deployment, hot wedge and extrusion welding, air pressure and vacuum testing, anchor trench and penetration detailing, as-built records.
InstallationHDPE lining systems
Complete lining for reservoirs, lagoons, canals, landfill cells and bunds — single liner, composite liner with geotextile, or double liner with a leak detection layer.
Lining systemsHDPE sheet suppliers in UAE
Engineering-grade HDPE plate for fabrication, wear protection, tank lining and chute liners, cut and machined to your drawing.
HDPE sheetProtection, repair and accessories
Geotextile and protection layers
Non-woven needle-punched geotextile from 150 g/m² to 800 g/m² as a cushion beneath the liner, a protection layer above it, or separation over soft ground — specified against your subgrade.
Protection layersGeomembrane repair and relining
Leak location on ponds already losing water, extrusion-welded patching, panel replacement and complete relining where an old liner has reached the end of its life.
Repair and reliningPre-fabricated liner panels
Multiple sheet widths welded together under factory conditions, folded and palletised for sites that cannot take a full roll or where site welding time has to be minimised.
Ask about panelsHow the services fit together on a typical reservoir
A 5,000 m² irrigation reservoir in Al Ain is the most common job we quote. Here is which services it draws on and why.
| Stage | Service used | What it covers |
|---|---|---|
| 1 | Take-off and design check | Converting plan area to developed area including 1V:2.5H slopes and a 500 mm anchor trench — usually 12–18 % more sheet than the plan area suggests |
| 2 | Geomembrane supply | 1.00 mm smooth black HDPE, roll widths chosen to minimise the number of field seams |
| 3 | Geotextile | 200 g/m² non-woven cushion where the subgrade contains gravel or gypsum crust |
| 4 | Installation | Deployment, hot wedge seaming, extrusion welding at the inlet penetration and sump |
| 5 | Testing | Air pressure testing of every dual-track seam, vacuum box on extrusion welds and patches |
| 6 | Handover | Panel layout as-built, weld log, test results, material certificates, repair register |
Take away stages 4 to 6 and you have a supply-only order. Add a leak detection layer between two liners and it becomes a double-lined containment cell. The price guide shows what each stage adds per square metre.
Ask for a scope and a price
Give us the area in square metres, the liner thickness and the application. We reply with a written quotation, material data sheet and an indicative delivery date.
Answers for specifiers & buyers
Frequently asked questions
Can I buy the geomembrane without installation?
Yes — supply-only is a large share of what we do. You receive the rolls, the material certificates and, if you want it, a panel layout drawing so your own crew knows the deployment order. Welding equipment hire and a supervisor for the first day can be added if your team is new to hot wedge welding.
Do you handle small jobs, or only large contracts?
Both. A 200 m² fish pond and a 40,000 m² landfill cell are quoted from the same rate structure, though small areas carry a minimum mobilisation charge if we install. For very small areas, supply-only with a pre-fabricated panel is usually the economical route.
Can you work to a consultant's specification?
Yes. Send the specification section and we will confirm compliance clause by clause, flag anything that is not achievable with the grades available locally, and price to what the document actually requires rather than to a generic assumption.
Do you supply geotextile as well as geomembrane?
Yes, non-woven needle-punched geotextile from 150 g/m² to 800 g/m². It is quoted alongside the liner because the two are usually installed in one operation, and the geotextile weight should be selected against the subgrade and the liner thickness together rather than picked independently.
